Planet IKVM-17080: Drawer 8 Port Combo-Free IP KVM Console with 17″ LCD Display

Danh mục:

Mô tả

Thông số kỹ thuật IKVM-17080

ModelIKVM-17080
Hardware Interface
PC Port8
PC Port Connector(All Female Type)Keyboard:3-in-1 HDDB 15 pin Female
Mouse:3-in-1 HDDB 15 pin Female
Monitor:3-in-1 HDDB 15 pin Female
Console ConnectionKeyboard:Mini DIN 6 pin Female
Mouse:Mini DIN 6 pin Female
Monitor:HDDB 15 pin Female
Mouse USB:USB (TYPE A)
Keyboard USB(Female):USB (TYPE A)
Keyboard Mouse105 keys keyboard with touch pad
Touch Pad1000 points / inch (40 points / mm) graphics tablet mode
Control Feature
Max. PC Connections64 (by cascade 8 KVM-810)
Port Selection Keys8
PC SelectionOn Screen Display Menu / Hot Key / Button
KVM Video ResolutionUp to 1920 x 1440 60Hz
Hardware Specification & Environment
Display Size17 inches
Panel Type4CCFL LCD Panel
LCD Resolution CapabilitiesMaximum Resolution up to 1280 x 1024 (SXGA)
Pixel Pitch0.264 (H) x 0.264 (V)
0.294 (H) x 0.294 (V)
Backlight Lifetime50,000 hours
Operating SystemWindows 98SE / ME / 2000 / XP / 2003 / Vista / 7 Server, Linux,
Mac OS9 / OSX, Sun Microsystems
Chassis ConstructionHeavy duty steel materials
Rail Slide Dimension45 cm (extended length 22cm)
Dimension (W x D x H)440 x 450 x 44 mm
Weight10.5 Kg
Environmental SpecificationOperating: 5 ~ 40 Degree C (41 ~ 104 Degree F)
Storage: -20 ~ 60 Degree C ( -4 ~ 140 Degree F)
Relative humanity: 0 ~ 80% (non-condensing)
Power RequirementUniversal 100~240V AC input
CertificationFCC, CE
