QNAP TES-1885U

QNAP TES-1885U

Powered by an Intel® Xeon® D processor, the powerful enterprise-class TES-1885U is open for two operating systems – either the FreeBSD-based QES or Linux-based QTS. While QES supports ZFS for the utmost reliability and allows near-limitless snapshots, block-level data dedu

Danh mục:

Mô tả

Thiết bị lưu trữ QNAP TES-1885U

Ordering P/N TES-1885U-D1521-16GR
TES-1885U-D1521-32GR
TES-1885U-D1531-32G
TES-1885U-D1531-64G
TES-1885U-D1531-16GR
TES-1885U-D1531-32GR
TES-1885U-D1531-128GR
CPU
TES-1885U-D1521-16GR / TES-1885U-D1521-32GR:
Intel® Xeon® Processor D-1521, 4-core 2.4 GHz

TES-1885U-D1531-32G / TES-1885U-D1531-64G / TES-1885U-D1531-16GR / TES-1885U-D1531-32GR / TES-1885U-D1531-128GR:
Intel® Xeon® Processor D-1531, 6-core 2.2 GHz

System memory Total DIMM slots: 4
Maximum memory: DDR4 128 GB ( 32 GB RDIMM x 4 )
Memory modules pre-installed:
TES-1885U-D1521-16GR: 16 GB ECC RAM ( 8 GB RDIMM x 2 )
TES-1885U-D1521-32GR: 32 GB ECC RAM ( 8 GB RDIMM x 4 )
TES-1885U-D1531-32G: 32 GB non-ECC RAM ( 16 GB UDIMM x 2 )
TES-1885U-D1531-64G: 64 GB non-ECC RAM (16 GB UDIMM x 4 )
TES-1885U-D1531-16GR: 16 GB ECC RAM ( 8 GB RDIMM x 2 )
TES-1885U-D1531-32GR: 32 GB ECC RAM ( 8 GB RDIMM x 4 )
TES-1885U-D1531-128GR: 128 GB ECC RAM ( 32 GB RDIMM x 4 )

Note: TES-1885U requires at least 32GB RAM for running QES operating system.

Flash Memory 4 GB DOM
Hard Drive Tray Front: 2.5″ / 3.5″ x 12
Rear: 2.5″ SSD slot x 6
Supported Hard Drive Front: SAS 12Gb/s, SAS 6Gb/s, SATA 6Gb/s HDD and SSD
Rear: SATA 6Gb/s SSD
USB 2 x USB 3.0 port (rear)
Support USB printer, pen drive, USB hub, and USB UPS etc.
LAN Port 2 x SFP+ 10GbE ports, 4 x Gigabit ports
LED Indicators 10 GbE, Status, LAN, Storage expansion port status
Buttons System: Power button and reset button
Form Factor 2U, Rackmount
Dimensions (H x W x D) 88 x 442.5 x 530.5 mm
3.46 x 17.42 x 20.89 inch
Weight Net weight (NAS only): 15.1 kg / 32.28 lb
Gross weight (with packing and accessories): 21.41 kg / 47.20 lb
Temperature 0-40˚C
Relative Humidity 5~95% non-condensing, wet bulb: 27˚C.
Power Supply Redundant power: Input 90~264VAC; 450W x 2
