Synology RS1619xs+

Synology RS1619xs+

NAS Synology RS1619xs+ 4-bay RackStation (up to 16-bay), Quad Core 2.4 GHz, 8GB RAM (up to 64GB), Redundant Power

Danh mục:

Mô tả

Thiết bị lưu trữ NAS Synology RS1619xs+

Hardware Specifications
CPU
CPU ModelIntel Xeon D-1527
CPU Architecture64-bit
CPU FrequencyQuad Core 2.2 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI)Yes
Memory
System Memory8 GB DDR4 ECC UDIMM
Memory Module Pre-installed8 GB (8 GB x 1)
Total Memory Slots4
Memory Expandable up to64 GB (16 GB x 4)
Storage
Drive Bays4
Maximum Drive Bays with Expansion Unit16
M.2 Drive Slots2 (NVMe & SATA)
Compatible Drive Type
  • 3.5″ SATA HDD
  • 2.5″ SATA HDD
  • 2.5″ SATA SSD
  • M.2 2280 NVMe & SATA SSD
Maximum Internal Raw Capacity64 TB (16 TB drive x 4) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units256 TB (64 TB + 16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Single Volume Size
  • 200 TB (32GB RAM required, for RAID 5 or RAID 6 groups only)
  • 108 TB
Hot Swappable DriveYes
External Ports
RJ-45 1GbE LAN Port4 (with Link Aggregation / Failover support)
USB 3.0 Port2
Expansion Port1
PCIe
PCIe Expansion1 x Gen3 x8 slot (x8 link)
Add-In-Card SupportPCIe Network Interface Card
Redundant Power SupplyYes
Supported RAID Type
  • RAID F1
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
