Switch Aruba 8400 8-slot chassis Bundle (JL375A)

Switch Aruba 8400 8-slot chassis Bundle (JL375A)

Aruba 8400 8-slot Chassis/3xFan Trays/18xFans/Cable Manager/X462 Bundle (JL375A): Aruba 8400 8-slot chassis, 3 x Fan Trays, 18 x Fans, Cable Manager, X462 2-post Rack Rail Kit.

Danh mục:

Mô tả

Thiết bị mạng Switch Aruba 8400 8-slot chassis Bundle (JL375A)

Product NameAruba 8400 8-slot Chassis/3xFan Trays/18xFans/Cable Manager/X462 Bundle (JL375A)
Line modules and slotsSupports a maximum of 256 10GbE (SFP/SFP+) ports, or 64 40GbE (QSFP+) ports, or 48 ports 40/100GbE (QSFP28) combination

Eight slots for line modules

Module VoQ1.5GB for JL363A and JL365A

3GB for JL366A

Additional ports and slots2 Management Module slots

3 Fabric Module slots

4 Power Supply slots

Power supplies4 power supply slots

2 minimum power supply required for a fully loaded chassis (or with 8 Line Modules)

Fan trayIncluded with JL376A
Physical characteristicsDimensions: 17.4(w) x 26(d) x 13.8(h) in. (44.1 x 66.0 x 35.1 cm) (8U height)
Weight:

-Empty configuration weight: 76 lbs (34 kg)

-JL376A weight: 164 lbs (74 kg)

-Full configuration weight: 241 lbs (109 kg)

Reliability99.999%
Mounting and enclosureMounts in an EIA standard 19-inch rack or other equipment cabinet (hardware included); horizontal surface mounting only
EnvironmentOperating: 32°F to 104°F (-0°C to 40°C) with 5% to 95%, non-condensing

Non-Operating: -40°F to 158°F (-40°C to 70°C) with 5% to 95%, non-condensing

Max Operating Altitude: Up to 10,000ft (3.048 Km)

Max Non-Operation Altitude: Up to 30,000ft (9.144 Km)

Acoustics: Sound Power (LWAd) 7.3 Bel, Sound Pressure (LpAm) (Bystander) 55.6 dB

Electrical characteristicsFrequency: 47-63 Hz

AC voltage: 90 – 140/180 – 264 VAC

DC voltage

Current: 16 A

Power output: 2750 W

ManagementSNMP, RJ-45 serial; USB micro USB console; RJ-45 Ethernet port
Tùy chọn module dùng cho Switch Aruba ​JL375A
JL363AAruba 8400X 32-port 10GbE SFP/SFP+ with MACsec Advanced Module
JL365AAruba 8400X 8-port 40GbE QSFP+ Advanced Module
JL366AAruba 8400X 6-port 40GbE/100GbE QSFP28 Advanced Module
JL367AAruba 8400X 7.2Tbps Fabric Module
JL368AAruba 8400 Management Module
Tùy chọn Fans và Power Supply dùng cho Switch Aruba ​JL375A
JL369AAruba X731 Fan Tray
JL370AAruba 8400 Fan for X731 Fan Tray
JL371AAruba 8400 1 Fan Tray and 6 Fans Bundle
JL372AAruba X382 54VDC 2700W AC Power Supply
JL373AAruba X464 4-post Rack Rail Kit
JL374AAruba X462 2-post Rack Rail Kit
Tùy chọn module quang SFP dùng cho Switch Aruba ​JL375A
J4858CHPE X121 1G SFP LC SX Transceiver
J4859CHPE X121 1G SFP LC LX Transceiver
J4860CHPE X121 1G SFP LC LH Transceiver
J8177CHPE X121 1G SFP RJ45 T Transceiver
J9281BHPE X242 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
J9283BHPE X242 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
J9285BHPE X242 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
J9150AHPE X132 10G SFP+ LC SR Transceiver
J9151AHPE X132 10G SFP+ LC LR Transceiver
J9153AHPE X132 10G SFP+ LC ER Transceiver
J9152AHPE X132 10G SFP+ LC LRM Transceiver
JL563A1Aruba 10GBASE-T SFP+ RJ45 30m Cat6A Transceiver
JH234AHPE X242 40G QSFP+ to QSFP+ 1m Direct Attach Copper Cable
JH235AHPE X242 40G QSFP+ to QSFP+ 3m Direct Attach Copper Cable
JH236AHPE X242 40G QSFP+ to QSFP+ 5m Direct Attach Copper Cable
JL308AAruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver
JH231AHPE X142 40G QSFP+ MPO SR4 Transceiver
JH233AHPE X142 40G QSFP+ MPO eSR4 300M Transceiver
Q9G82AAruba 40G QSFP+ LC ER4 40km SMF Transceiver
JH232AHPE X142 40G QSFP+ LC LR4 SM Transceiver
JL307AAruba 100G QSFP28 to QSFP28 3m Direct Attach Copper Cable
JL309AAruba 100G QSFP28 MPO SR4 100m 12-fiber MPO OM3 MMF Transceiver
JL310AAruba 100G QSFP28 LC LR4 10km SMF 2-strand Transceiver
