FortiADC 60F (FAD-60F)

FortiADC 60F (FAD-60F)

FAD-60F – Load Balancing FortiNet FortiADC 60F, 5x GE RJ45 ports, 64 GB SSD.

Danh mục:

Mô tả

Thiết bị cân bằng tải FortiNet FortiADC 60F

Mã sản phẩm FAD-60F
Hardware Specifications
L4/L7 Throughput 400 Mbps / 200 Mbps
L4 CPS 15,000
L4 HTTP RPS 45,000
Maximum L4 Concurrent Connection 1M
L7 CPS (1:1) 5,000
SSL CPS/TPS (1:1) 2K keys 50
SSL Bulk Encryption Throughput 240 Mbps
Compression Throughput 400 Mbps
SSL Acceleration Technology Software
Memory 4 GB
Virtual Domains 0
Network Interfaces 5x GE R45
10/100/1000 Management Interface
Storage 64 GB SSD
Management HTTPS, SSH CLI, Direct Console DB9 CLI, SNMP
Power Supply Single
Environment
Form Factor 1U Appliance
Input Voltage 100–240V, 50–60Hz
Power Consumption (Average / Maximum) 14.3 W / 11.9 W
Maximum Current 115Vac/0.9A, 230Vac/0.6A
Heat Dissipation 49 BTU/h
Operating Temperature 32–104°F (0–40°C)
Storage Temperature -31–158°F (-35–70°C)
Humidity 20–90% non-condensing
Compliance
Regulatory Compliance FCC Part 15 Class A, C-Tick, VCCI, CE, UL/c
Safety CSA, C/US, CE, UL
Dimensions
Height x Width x Length (in) 1.5 x 8.5 x 6.3
Height x Width x Length (mm) 38 x 216 x 160
Weight 2.2 lbs (1 kg)
