Bridge Router Planet GRT-501: G.SHDSL.bis Bridge Router (1x RJ-45, 1x RJ-11)

Mô tả

Thiết bị mạng Bridge Router Planet GRT-501

ProductG.SHDSL Bridge Router
ModelGRT-501
Hardware
StandardCompliant with ITU-T G.991.2 Standard Annex A / B
Compliant with G.SHDSL.bis Annex A / B / F / G
TC-PAM Line Code
Symmetric data transmission speed up to 5.7 Mbps on 2-wire
Multi-range from 192kbps to 5.7Mbps
ProtocolRFC 1577 – Classical IP over ATM (RFC 1577)
RFC 2364 – PPP over ATM
RFC 1483 / 2684 – Ethernet over ATM
RFC 2516 – PPP over Ethernet (fixed and dynamic IP)
RFC 2364 – PPP over ATM (fixed and dynamic IP)
AAL and ATM SupportSupports up to 8PVCs
ATM Forum UNI 3.1 / 4.0 PVC
Supports OAM F4 / F5 AIS / RDI and loopback
VC multiplexing and SNAP / LLC
Integrated ATM QoS support (UBR,CBR,VBR-rt, and VBR-nrt)
LAN Port1 x 10Base-T / 100Base-TX ( Auto-Negotiation, Auto MDI / MDI-X)
Console1 x RS-232 (DB9)
Button1 x Reset Button
LED IndicatorsPWR, WAN LNK / ACT, LAN 10M/100M, ALM
Software
ProtocolIEEE 802.1D transparent learning bridge
IEEE 802.1Q VLAN
Supports IP / TCP / UDP / ARP / ICMP / IGMP protocols
IP routing with static routing and RIPv1 / RIPv2
IP multicast and IGMP proxy
Network address translation (NAT / PAT)
DMZ host / Multi-DMZ / Multi-NAT function
Virtual Server (RFC1631)
DNS relay and caching
DHCP server, client and relay
SecurityBuilt-in NAT Firewall
PPP over PAP (RFC1334)
PPP over CHAP (RFC1994)
Password protection for system management
VPNVPN (PPTP / L2TP / IPSec) pass-through
ManagementWeb-based configuration
Command-line Interpreter (CLI) via Console
Command-line Interpreter (CLI) via Telnet
Upgrades Software via web-browser / TFTP server
SNMPv1 and v2
Environment Specification
Dimension (W x D x H)145 x 188 x 33mm
Power9V DC, 1A
Temperature
Humidity
Operating: 0~45 degree C, 0%~ 90% (non-condensing),
Storage: -10~70 degree C, 0~95% (non-condensing)
