Cisco ASA5506-SEC-BUN-K9

Cisco ASA5506-SEC-BUN-K9

Cisco ASA5506-SEC-BUN-K9 ASA 5506 with FirePOWER services and Sec Plus license. Hàng chính hãng bảo hành 12 – 60 tháng, đầy đủ CO, CQ do Cisco Việt Nam cấp.

Danh mục:

Mô tả

Thiết bị tường lửa Firepower Cisco ASA5506-SEC-BUN-K9

Product Number ASA5506-SEC-BUN-K9
Product Description ASA 5506-SEC-BUN-X with FirePOWER services, WiFi for Europe, 8GE Data, 1GE Mgmt, AC, 3DES/AES
Throughput: Application Control (AVC) 250 Mbps
Throughput: Application Control (AVC) and IPS 125 Mbps
Maximum concurrent sessions 20,000; 50000
Maximum New Connections per second 5,000
Supported applications More than 3,000
URL categories 80+
Number of URLs categorized More than 280 million
Centralized configuration, logging, monitoring, and reporting Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center
On-Device Management ASDM (version 7.3 or higher required)
Feature Cisco ASA 5506W-X w/ FirePOWER Services
Stateful inspection throughput (maximum) 750 Mbps
Stateful inspection throughput (multiprotocol) 300 Mbps
Triple Data Encryption Standard/
Advanced Encryption Standard (3DES/AES) VPN throughput
100 Mbps
Users/nodes Unlimited
IPsec site-to-site VPN peers 10; 50
Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections 50
Virtual interfaces (VLANs) 5; 30
Security contexts5 (included; maximum) N/A
High availability Requires Security Plus License; Active/ Standby
Integrated Wireless Access Point

(See Cisco AP 702 datasheet for WiFi technical details)

Wireless Bands a/b/g/n; Max n wifi throughput 54 Mbps; internal antenna only; local management or centralized via Cisco WLC
Expansion slot N/A
User-accessible Flash slot No
USB 2.0 ports USB port type ‘A’, High Speed 2.0
Integrated I/O 8 x 1 Gigabit Ethernet (GE)
Expansion I/O N/A
Dedicated management port Yes (To be shared with FirePOWER Services), 10/100/1000
Serial ports 1 RJ-45 and Mini USB console
Solid-state drive 50 GB mSata
Memory 4 GB
System flash 8 GB
System bus Multibus architecture
Temperature 32 to 104°F (0 to 40 °C)
Relative humidity 90 percent noncondensing
Altitude Designed and tested for 0 to 10,000 ft (3048 m)
0 dBA
Temperature -13 to 158ºF (-25 to 70ºC)
Relative humidity 10 to 90 percent noncondensing
Altitude Designed and tested for 0 to 15,000 ft (4572 m)
AC range line voltage External, 90 to 240 volts alternating current (VAC)
AC normal line voltage 90 to 240 VAC
AC current N/A
AC frequency 50/60 Hz
Dual-power supplies None
DC domestic line voltage N/A
DC international line voltage N/A
DC current N/A
Steady state 12V @2.5A
Maximum peak 12V @ 5A
Maximum heat dissipation 103 British thermal units (Btu)/hr
Form factor Desktop, rack mountable
Dimensions (H x W x D) 1.72 x 7.871 x 9.23 in.(4.369 x 19.992 x 23.444 cm)
Weight (with AC power supply) 4 lb (1.82 kg)
