UniFi Switch US-8

Switch Unifi US-8 is a PoE Powered 8-port gigabit switch with PoE Passthrough. Perfect for cleanly adding Ethernet ports where needed, with passthrough to keep your PoE device powered.

Danh mục:

Mô tả

Thiết bị mạng Switch Unifi US-8

Product
US-8
Dimensions 148.0 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21″)
Weight 432 g (15.24 oz)
Enclosure Characteristics SGCC Steel
Total Non-Blocking Throughput 8 Gbps
Switching Capacity 16 Gbps
Forwarding Rate 11.9 Mpps
Max. Power Consumption 12W (Excluding PoE Output)
Max. Passive PoE Wattage per Port PoE Mode 1: 12W @ 802.3at PoE Mode 2: 12W @ 48V DC Input Mode: 12W @ 48V
Passive PoE Voltage Range Depends on Power Source
Power Method (1) DC 48V, Max. 1.25A (1) PoE Input, 802.3 af/at (Pins +1, 2; -3, 6)
Supported Voltage Range DC: 48V; 48V Mode: 56V to 40V
Power Supply External AC/DC Adapter, 48V, 0.5A
LEDs PoE (Port 8), Speed/Link/Activity (All Ports)
Sound Level* 0.7 dBr (Fanless)
Networking Interfaces (8) 10/100/1000 Mbps RJ45 Ports
PoE In Interface (Port 1) PoE Mode 1: 802.3af/at (Pins +1, 2; -3, 6)

PoE Mode 2: 48V (2-Pair Pins +4, 5; -7, 8)
PoE Out Interface (Port 8) PoE Mode 1: 48V (Pins +1, 2; -3, 6)

PoE Mode 2: Passive 48V (2-Pair Pins +4, 5; -7, 8)

DC Input Mode: DC Passthrough

(Pins +1, 2; -3, 6)
Management Interface Ethernet In-Band Management
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature -5 to 45° C (23 to 113° F)
Operating Humidity 5 to 95% Noncondensing
Shock and Vibration ETSI300-019-1.4 Standard
Certifications CE, FCC, IC
