Unifi EdgeSwitch ES‑16‑XG

Unifi EdgeSwitch ES‑16‑XG

Switch Unifi EdgeSwitch ES‑16‑XG Non-Blocking Throughput, 16-Port with 10G Ethernet SFP+ and RJ45 Ports Managed Aggregation Switch.

Mô tả

Thiết bị mạng Switch Unifi EdgeSwitch ES-16-XG

Product
ES-16-XG
Dimensions
443 x 221 x 43 mm (17.44 x 8.70 x 1.69″)
Weight
Without Mount Brackets
With Mount Brackets
2.62 kg (5.78 lb)2.71 kg (5.97 lb)
Total Non-Blocking Throughput
160 Gbps
Enclosure Characteristics
SGCC Steel
Switching Capacity
320 Gbps
Forwarding Rate
238.10 Mpps
Max. DC Power Consumption
36W (Excludes SFP/SFP+ Modules)
Power Method
AC
DC
100-240VAC/50-60 Hz, Universal InputDC 56W, 25 to 16V, with 2.5 mm DC Power Inline Connector
Power Supply
AC/DC, Internal, 56W DC
Supported Voltage Range
AC: 100 to 240VAC
DC: 25 to 16VDC
LEDs Per Port
Speed/Link/Activity
Networking Interfaces
(12) 1/10 Gbps SFP+ Ethernet Ports
(4) 1/10 Gbps RJ45 Ethernet Ports
Management Interface
(1) RJ45 Serial Port, Ethernet In/Out Band
Certifications
CE, FCC, IC
Wallmount
Yes
ESD/EMP Protection
Air: ±24 kV, Contact: ±24 kV
Operating Temperature
-5 to 40° C (23 to 104° F)
Operating Humidity
5 to 95% Noncondensing
Shock and Vibration
ETSI300-019-1.4 Standard
