Switch Planet GS-4210-16T2S: 16-Port 10/100/1000T + 2-Port 100/1000X SFP Managed Switch

Mô tả

Thiết bị mạng Switch Planet GS-4210-16T2S

ProductGS-4210-16T2S
Hardware Specifications
Hardware Version2
Copper Ports16 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
SFP/mini-GBIC Slots2 x 100/1000BASE-X SFP interfaces, supporting 100/1000Mbps dual mode
Console1 x RS232-to-RJ45 serial port (115200, 8, N, 1)
Reset ButtonSystem factory default
Switch ArchitectureStore-and-Forward
Switch Fabric36Gbps/non-blocking
Switch Throughput@64 bytes26.7Mpps @64 bytes
MAC Address Table8K entries
Shared Data Buffer4.1 megabits
Flow ControlIEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame9216 bytes
Reset Button> 5 sec: Factory default
LEDSystem: Power (Green)
10/100/1000T RJ45 Interfaces (Port 1 to Port 16): 1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange)
100/1000Mbps SFP Interfaces (Port 17 to Port 18): 1000 LNK/ACT (Green), 100 LNK/ACT (Orange)
Power Requirements100~240V AC, 50/60Hz, 0.8A (max.)
Power Consumption/DissipationMax. 10.4 watts/35 BTU
Dimensions (W x D x H)445 x 207 x 45 mm (1U height)
Weight2kg
ESD ProtectionYes
EnclosureMetal
Layer 2 Functions
Port MirroringTX/RX/both
Many-to-1 monitor
VLAN802.1Q tagged-based VLAN
Up to 256 VLAN groups, out of 4094 VLAN IDs
802.1ad Q-in-Q tunneling (VLAN stacking)
Voice VLAN
Protocol VLAN
Private VLAN (Protected port)
GVRP
Management VLAN
Link AggregationIEEE 802.3ad LACP and static trunk
Supports 8 groups of 8-port trunk
Spanning Tree ProtocolIEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
STP BPDU Guard, BPDU Filtering and BPDU Forwarding
IGMP SnoopingIPv4 IGMP (v2/v3) snooping
IGMP querier
Up to 256 multicast groups
MLD SnoopingIPv6 MLD (v1/v2) snooping, up to 256 multicast groups
Access Control ListIPv4/IPv6 IP-based ACL/MAC-based ACL
IPv4/IPv6 IP-based ACE/MAC-based ACE
QoS8 mapping IDs to 8 level priority queues
– Port number
– 802.1p priority
– DSCP/IP precedence of IPv4/IPv6 packets
Traffic classification based, strict priority and WRR
Ingress/Egress Rate Limit per port bandwidth control
SecurityIEEE 802.1X port-based authentication
Built-in RADIUS client to co-operate with RADIUS server
RADIUS/TACACS+ authentication
IP-MAC port binding
MAC filtering
Static MAC address
DHCP snooping and DHCP Option82
STP BPDU guard, BPDU filtering and BPDU forwarding
DoS attack prevention
ARP inspection
IP source guard
Storm control support
Broadcast/unknown unicast/unknown multicast
Management Functions
Basic Management InterfacesRJ45 Console; Web browser; Telnet; SNMP v1, v2c, v3
Firmware upgrade by HTTP/TFTP protocol through Ethernet network
Configuration upload/download through HTTP/TFTP
Remote/Local Syslog
System log
LLDP Protocol
SNTP
PLANET Smart Discovery Utility
Secure Management InterfacesHTTPs, SNMP v3
SNMP MIBsRFC 3635 Ethernet-like MIB
RFC 2863 Interface Group MIB
RFC 2819 RMON (1, 2, 3, 9)
RFC 1493 Bridge MIB
Standards Conformance
Regulatory ComplianceFCC Part 15 Class A, CE
Standards ComplianceIEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000BASE-T
IEEE 802.3x flow control and back pressure
IEEE 802.3ad port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1ab LLDP
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP version 1
RFC 2236 IGMP version 2
RFC 3376 IGMP version 3
RFC 2710 MLD version 1
RFC 3810 MLD version 2
Environment
OperatingTemperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
StorageTemperature: -10 ~ 70 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
